MSI PRO H610M-S DDR4 MOTHERBOARD (Intel)
- 12th Gen Intel Core, Pentium Gold, and Celeron processors
- LGA 1700 socket
- DDR4 Memory, up to 4600+(OC) MHz
- PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
- Upgraded network solution for professional and multimedia use.
Chat Through:
Original price was: 10,600৳ .9,800৳ Current price is: 9,800৳ .
Description
MSI PRO H610M-S DDR4 MOTHERBOARD Full Specification
Buy the MSI PRO H610M-S DDR4 MOTHERBOARD at Computer Mania BD for ৳9,800 with an official warranty. Get reliable performance at the best price in Bangladesh. Order online or visit our store today! Get the latest MSI Intel Motherboard by visiting our website.
| GPU Specification | |
| Multi-Display Capability | 12 |
| Motherboard Specification | |
| Chipset | Intel H610 Chipset |
| Form Factor | mATX Form Factor 9.29 x 7.95 in. (23.6 cm x 20.2 cm) |
| Audio | Realtek ALC892/ ALC897 Codec 7.1-Channel High Definition Audio |
| Socket | 1700 |
| Memory Specification | |
| Memory Type | DDR4 |
| Max Number of Channels | Dual |
| Memory Capacity | 64 |
| Memory Slots | 2 |
| Supports | |
| Supported CPU | Supports 12th Gen Intel Core Processors, Pentium Gold and Celeron Processors Processor socket LGA1700 |
| Supported Memory | Supports 1R 2133/ 2666/ 2933/ 3200 MHz (by JEDEC & POR) Supports Dual-Channel mode Supports non-ECC, un-buffered memory |
| Supported Storage | 4x SATA 6Gb/s ports 1x M.2 slot (Key M, from chipset) Supports up to PCIe 3.0 x4 Supports up to SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices Supports Intel Smart Response Technology for Intel Core processors |
| Connectors | |
| LAN | 1x Intel I219V 1Gbps LAN controller |
| USB | Intel H610 Chipset: 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector) 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0 connector) |
| HDMI | 1 |
| TPM (Trusted Platform Module ) | 1x TPM module connector |
| Ports & Slots | |
| Slots | M.2 SLOT 1 |
| Ports | USB 3.2 Ports (Front) 2(Gen 1, Type A) USB 3.2 Ports (Rear) 2(Gen 1, Type A) USB 2.0 Ports (Front) 2 USB 2.0 Ports (Rear) 4 Audio Ports (REAR) Realtek ALC892/ ALC897 Codec |
| Internal I/O Ports | POWER CONNECTORS: 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector FAN CONNECTORS: 1x 4-pin CPU fan connector 1x 4-pin system fan connector SYSTEM CONNECTORS: 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector |
| Expansion Slots | PCI 1x PCIe x16 slot (From CPU) Supports up to PCIe 4.0 x16 1x PCIe x1 slot Supports PCIe 3.0 x1 1x M.2 slot with E-key for PCIe WiFi module only (M2_ WIFI1) |
| Physical Specification | |
| Dimensions (W x D x H) | 304*243mm |
| Warranty Information | |
| Warranty | 3 Years Warranty |
Additional information
| Brand |
MSI |
|---|---|
| CPU Sockets |
LGA 1700 |
| FromFactor |
Micro ATX |
| RAM Type |
DDR4 |
| Special Features |
M.2 |
