Description
MSI PRO A620M-E DDR5 MATX Motherboard Full Specification
Buy the MSI PRO A620M-E DDR5 MATX Motherboard from Computer Mania BD at the best price in Bangladesh. Get it now with an official warranty. Check out features, and reviews, and order online today!
| Motherboard Specification | |
| Chipset | AMD A620 |
| Form Factor | M-ATX |
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| Socket | AMD AM5 |
| Memory Specification | |
| Memory Type | DDR5 |
| Memory Capacity | 96GB |
| Network & Wireless | |
| LAN | Realtek® RTL8111H Gigabit LAN |
| Supports | |
| Supported CPU | Supports AMD Ryzen™ 7000 Series Desktop Processors |
| Supported Memory | 2x DDR5, Maximum Memory Capacity 96GB Memory Support DDR5 6000+(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6000+ MHz • 1DPC 2R Max speed up to 6000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO |
| Connectors | |
| USB | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
| HDMI | 1x HDMI™ Support HDMITM 2.1, maximum resolution of 4K 60Hz* |
| Display Port | 1x VGA Support VGA, maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz |
| Ports & Slots | |
| Slots | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| PCI-E | CI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Warranty Information | |
| Warranty | 3 Years Warranty |
Additional information
| Brand |
MSI |
|---|---|
| CPU Sockets |
AM5 |
| FromFactor |
Micro ATX |
| RAM Type |
DDR5 |
| Special Features |
M.2 |
