Description
MSI MAG B650 TOMAHAWK WIFI DDR5 Motherboard Full Specification
Buy the MSI MAG B650 TOMAHAWK WIFI DDR5 Motherboard at Computer Mania BD for the best price in Bangladesh – only ৳30,600. Enjoy top-tier performance, fast connectivity, and advanced features. Order online or visit our store today! Visit our website to get the latest MSI AMD Motherboard with the best deals.
| Motherboard Specification | |
| Chipset | AMD B650 |
| Form Factor | ATX |
| Audio | Realtek® ALC4080 Codec 7.1-Channel High-Performance Audio Supports S/PDIF output Supports up to 32-bit/384 kHz playback on the front panel |
| Socket | AM5 |
| Memory Specification | |
| Memory Type | DDR5 |
| Memory Capacity | 4x DDR5, Maximum Memory Capacity 192GB Memory Support DDR5 6000+(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6000+ MHz • 1DPC 2R Max speed up to 6000+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5400+ MHz |
| Network & Wireless | |
| Wi-Fi | AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.3** |
| LAN | Realtek® RTL8125B 2.5Gbps LAN |
| Supports | |
| Supported CPU | Supports AMD Ryzen™ 7000 Series Desktop Processors |
| Connectors | |
| USB | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) |
| HDMI | 1x HDMI™ Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz* |
| Display Port | 1x DisplayPort Support DP 1.4, the maximum resolution of 8K 60Hz* |
| Ports & Slots | |
| Slots | 2x PCI-E x16 slot Support x16/ x4 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x2 (From Chipset) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports |
| PCI-E | 2x PCI-E x16 slot Support x16/ x4 1x PCI-E x1 slot |
| Warranty Information | |
| Warranty | 3 Years Warranty |
Additional information
| Brand |
MSI |
|---|---|
| CPU Sockets |
AM5 |
| FromFactor |
ATX |
| RAM Type |
DDR5 |
| Special Features |
Wi-Fi |
