Description
Maxsun Terminator B760M GKD5 ICE Gaming Motherboard Full Specification
Buy Maxsun Terminator B760M GKD5 ICE Gaming Motherboard at the best price in Bangladesh from Computer Mania BD for just 17,000/- BDT. Experience top-tier gaming performance with advanced features. Upgrade your PC with the reliable Maxsun Intel Motherboard for top performance. Order online or visit our store today for the best deals on high-performance motherboards!
| Mainboard | |
| Chipset | Intel B760 High-speed chipset |
| Memory | |
| Memory Specifications | Dual DDR5 slots capable of reaching speeds up to 8000MHz |
| Storage | |
| Storage | 3 x M.2 slots (PCIe X4/X2 channel SSD only) 1 x M.2_WIFI slot (CNVI network card only) 4 x SATA3.0 ports |
| Display | |
| Display | 1 x DP1.4 interface (up to 7680×4320@30Hz) 1 x HDMI2.0 interface (up to 4096×2160@60Hz) |
| Networking & Connectivity | |
| Connectivity | 2.5G network card for high-speed connections |
| Bluetooth | v5.3 |
| Network Interface | Integrated REALTEK 8125B NIC chip (10/100/1000/2500Mbit) 1 x onboard RJ45 port Supports PXE diskless boot and UEFI diskless boot |
| Audio & Microphone | |
| Audio | Integrated REALTEK ALC897 sound card chip |
| Battery And Power | |
| TDP | PL1: 241W; PL2: 253W |
| Power | 8+1+1 phase power design for stable performance |
| Ports | |
| Power Connector | Includes a (1 x 24)-PIN ATX power connector and an (8+4)-Pin +12V power connector for stable power delivery. |
| External I/O Ports | 1 x PCIEX16 5.0 slot 1 x PCIEX4 3.0 open slot |
| USB | Rear ports: 2 x USB3.2 GEN2 ports, 6 x USB2.0 portsFront interface: 1 x USB3.2 Gen2x2 Type-C (20G), 1 set (2) USB3.2 GEN1 pins |
| Special Features | |
| RGB | Yes |
| Others | |
| Other Features | Aesthetic: Modern white theme appearance |
| Physical Specification | |
| Color | White |
| Form Factor | Micro-ATX, 245mm x 245mm |
| Technical Info | |
| Model | Terminator B760M GKD5 ICE |
| Warranty | 2 Years Warranty |
Additional information
| Brand |
MAXSUN |
|---|---|
| CPU Sockets |
LGA 1700 |
| FromFactor |
Micro ATX |
| RAM Type |
DDR5 |
| Special Features |
M.2 |
