ASRock B650M Pro RS AM5 Micro ATX Motherboard (AMD)
- B650M Pro RS
- Supported CPU: Ryzen 9000/8000/ 7000 Series Processors for Socket AM5
- Supported RAM: 4x DDR5, up to 256GB, 7200+(OC)
- Graphics Output: 1x HDMI, 1x DisplayPort
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
Chat Through:
Original price was: 21,900৳ .20,200৳ Current price is: 20,200৳ .
Description
ASRock B650M Pro RS AM5 Micro ATX Motherboard Full Specification
Buy the ASRock B650M Pro RS AM5 Micro ATX Motherboard at the best price of BD 20,200/- BDT from Computer Mania BD. Get top-tier performance, AM5 support, and advanced features for a seamless computing experience. Upgrade your PC with the ASRock AMD Motherboard and enjoy seamless efficiency. Order online now for fast delivery across Bangladesh!
| Basic Information | ||
| Supported CPU | Supports AMD Socket AM5 Ryzen 9000, 8000 and 7000 Series Processors | |
| Chipset | AMD B650 | |
| BIOS | – 256Mb AMI UEFI Legal BIOS with GUI support | |
| Form Factor | – Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm – 2oz Copper PCB | |
| Audio | – 7.1 CH HD Audio (Realtek ALC897 Audio Codec) – Nahimic Audio | |
| Expansion Slots | ||
| PCI | CPU: – 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* – 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode* Chipset: – 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module – Supports AMD CrossFire™ | |
| Memory | ||
| Type | DDR5 | |
| Slots | – 4 x DDR5 DIMM Slots | |
| Supported Memory | – Dual Channel DDR5 Memory Technology – Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)* – Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules | |
| Maximum Memory | Max. 256GB | |
| Graphics | ||
| Graphics | Integrated AMD RDNA graphics (Actual support may vary by CPU) – 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3, and max. resolution up to 4K 120Hz – 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz | |
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Display Port (s) | 1x DisplayPort 1.4 | |
| USB (s) | – 1 x USB 3.2 Gen2 Type-C (Rear) – 1 x USB 3.2 Gen2 Type-A (Rear) – 1 x USB 3.2 Gen1 Type-C (Front) – 6 x USB 3.2 Gen1 Type-A (2 Rear, 4 Front) – 8 x USB 2.0 (4 Rear, 4 Front) | |
| LAN Port (s) | – 2.5 Gigabit LAN 10/100/1000/2500 Mb/s – Dragon RTL8125BG – Supports Dragon 2.5G LAN Software – Smart Auto Adjust Bandwidth Control – Visual User-Friendly UI – Visual Network Usage Statistics – Optimized Default Settings for Game, Browser, and Streaming Modes – User Customized Priority Control | |
| Supported Storage | CPU: – 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode* Chipset: – 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* – 1 x M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x2 (32 Gb/s) mode* – 4 x SATA3 6.0 Gb/s Connectors | |
| RAID | – Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices – Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices | |
| Audio | 3 x Audio jacks | |
| Internal I/O Ports | Rear Panel I/O – 2 x Antenna Mounting Points – 1 x HDMI Port – 1 x DisplayPort 1.4 – 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) – 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) – 2 x USB 3.2 Gen1 Ports – 4 x USB 2.0 Ports – 1 x RJ-45 LAN Port – 1 x BIOS Flashback Button – HD Audio Jacks: Line in / Front Speaker / Microphone Connector | |
| TPM (Trusted Platform Module ) | – 1 x SPI TPM Header | |
| Others | ||
| Special Features | Superb Productivity – PCIe Gen5 (M.2) – Dual Channel DDR5 Rock-Solid Durability – 8+2+1 Power Phase, 50A Dr.MOS – Pre-Installed I/O Shield Ultrafast Connectivity – 2.5G LAN EZ Update – BIOS Flashback Button – ASRock Auto Driver Installer | |
| Bundled Software | Software – ASRock Motherboard Utility (A-Tuning) – ASRock Dragon 2.5G LAN Software – ASRock Polychrome SYNC* UEFI – ASRock Full HD UEFI – ASRock Auto Driver Installer – ASRock Instant Flash | |
| Warranty Information | ||
| Warranty | 3 Years Warranty | |
Additional information
| Brand |
ASRock |
|---|---|
| CPU Sockets |
AM5 |
| FromFactor |
Micro ATX |
| RAM Type |
DDR5 |
| Special Features |
M.2 |
